Elevators and vertical platform lifts cannot reach every corner or surface of a home or building. Instead of having mobility restricted from one floor to another, maintain full independence with an inclined wheelchair lift. Perfect for moving between two floors, the Delta IPL is an economical accessibility solution.

A rail system and folding platform make full use of the stairs a possibility for everyone. The rail system easily mounts alongside the staircase, while the platform, available in an ADA-compliant size, folds up at both ends. Battery power prevents the system from stalling during a power outage, and chargers at both ends ensure the Delta IPL is consistently reliable. Additionally, this efficient mechanism eliminates the need for a machine room.

Compact and efficient, the Delta IPL prevents stairs from being less of a hindrance to a second floor or basement. For improving accessibility inside a two-floor structure with a straight staircase, go with the Delta IPL.

OUR PRODUCTS

Additional Information

Standard Features

  • 550 lb or 660 lb Capacity
  • 20 fpm rated speed
  • Rack & Pinion drive system
  • Standard platform size of 27″ x 36″
  • 42″ high platform side guard panels
  • Travel capability of up to 82 feet
  • Emergency battery powered raising and lowering with automatic battery recharging system
  • Automatic emergency lighting for added safety
  • Emergency alarm/stop button
  • 115 VAC operation
  • Keyed call/send stations

Optional Features

  • Public building package (needed for commercial applications)
  • 90º Platform
  • Folding seat on platform
  • Colors & Finishes
  • The Delta IPL comes standard with powder coated beige finish. Custom colors are available.

Colors and Finishes

The Delta IPL comes standard with powder coated beige finish. Custom colors are available.

Apex Delta IPL Drawings and Guides
