With the Apex Hydro, travel straight to the destination instead of going around a multi-floor system of ramps. A hydraulic system propels this smooth and reliable vertical platform wheelchair lift, which moves passengers as far as 14 feet. Designed for residential and commercial accessibility, the Apex Hydro not only expands independence but it also can be configured to specific mobility and aesthetic requirements.

Installation is straightforward, as neither machine room nor pit is needed. Instead, the wheelchair lift gives an even and stable ride through a rail system enclosed in a tower. The ADA-compliant, non-skid platform prevents the wheelchair from wobbling in transit, while the emergency stop button and sensors further enhance safety.

Take accessibility and efficiency in your home or commercial building to a new level, all while keeping style intact, with the Apex Hydro.


Additional Information

Standard Features

  • 750 lb Capacity
  • 25 fpm rated speed
  • Hydraulic drive system for smooth operation
  • Standard cab platform of 34″ wide by 54″ deep
  • 42″ high platform side guard panels
  • Travel capability of up to 12 feet with up to 2 stops
  • No pit required (3″ pit recommended to avoid ramp)
  • Emergency battery powered lowering with automatic battery recharging system
  • Automatic emergency lighting for added safety
  • Constant pressure up/down buttons
  • Emergency alarm/stop button
  • 115 VAC operation

Optional Features

  • Keyed call/send stations
  • Landing gates or landing doors
  • Public building package (needed for commercial applications)
  • Outdoor operation
  • Front/back and side exit configurations
  • Telephone on platform
  • Folding seat on platform

Colors and Finishes

The Apex Green comes standard with powder coated beige finish. Optional acrylic inserts or custom colors are availible.

Apex Green Drawings and Guides

  • Doors Opposite Sides Cab: PDF | DWG
  • Doors 90 Degree Left Cab: PDF | DWG
  • Doors 90 Degree Right Cab: PDF | DWG
